Mechanical Feed-Dual Carrier Metal Strip
NOTES
1.
2.
3.
4.
5.
Molex recommends an extra perishable tooling kit be maintained at your facility.
Verify tooling alignment by manually cycling the press with applicator before crimping under power. Check that all screws are tight.
Slugs, terminals, dirt, and oil should be kept clear of work area.
Wear safety glasses at all times.
For recommended maintenance refer to the Mini-Mac Applicator Manual (Document no. 63880-0000).
CAUTION : This applicator should only be used in a press with a shut height of 135.80 mm (5.346 ” ). Tooling damage could
result at a lower setting.
CAUTION : To prevent injury, never operate this applicator without the guards supplied with the press or wire-processing
machine in place. Reference the press or wire processing manufacturer ’ s instruction manual.
CAUTION : Molex crimp specifications are valid only when used with Molex terminals, applicators and tooling.
Contact Information
For more information on Molex application tooling please contact Molex at 1-800-786-6539.
Molex Application Tooling Group
1150 E. Diehl Road
Naperville, IL 60563
Tel: (630) 969-4550
Fax: (630) 505-0049
Visit our Web site at http://www.molex.com
Doc No. 63832-1100
Revision: A
Release Date: 12-05-05
Revision Date: 12-05-05
UNCONTROLLED COPY
Page 5 of 5
